향상된 Time Domain Analysis 기법을 이용한 Full-Bridge LLC 공진형 컨버터의 전력 손실 해석 Power Loss Analysis of Full-Bridge LLC Resonant Converter Using Enhanced Time Domain Analysis Method

논문 기본 정보

저자정보
(Hanyang University) (Hanyang University) (Tech University of Korea) (Hanyang University)
저널정보
대한전기학회 전기학회논문지 전기학회논문지 제74권 제7호
발행연도
수록면
1,237 - 1,247 (11page)
DOI
10.5370/KIEE.2025.74.7.1237
오류 신고하기

피인용 0

향상된 Time Domain Analysis 기법을 이용한 Full-Bridge LLC 공진형 컨버터의 전력 손실 해석
검색

    초록·키워드

    This paper proposes a method for analyzing power loss in a full-bridge LLC resonant converter based on the enhanced Time-Domain Analysis (TDA) technique. The proposed enhanced TDA method demonstrates that the power loss in an LLC resonant converter can be expressed through a complete equation. The necessary initial values are represented in equations, showing a deviation of less than 5% compared to simulation results. Furthermore, based on an 8.4kW full-bridge LLC resonant converter prototype, the proposed method and experimental values are compared in terms of efficiency across different loads, with a maximum error of 1.7% under light loads, while exhibiting highly similar values in other regions.
